Technical Data
Approvals
UL and C-UL Listed
NYC Approved under MEA 177-03-E (The listings apply only to the service conditions indicated in the Design Criteria section.)
Approvals for Air & Dust Seal
UL and C-UL
Listed Refer to Table A for complete approval information
Maximum Working Pressure 175 psi (12,1 bar)
Discharge Coefficient K= 11.2 gpm/psi½ (161,3 lpm/bar½)
Temperature Rating
160°F (71°C) Sprinkler/
139°F (59°C) Plate 212°F (100°C) Sprinkler/
165°F (74°C) Plate Adjustment 3/4 in. (19,1 mm)
